| Nominal shaft dia. mm | Resin retainer | mm | dr | |||
| Tolerance µm | ||||||
| Standard type LM...UU | Ball circuit | Weight (gf) | Precision | High | ||
| 3 | LM3 | 4 | 1.35 | 3 | 0 -5 | 0 -8 |
| 4 | LM4 | 4 | 1.9 | 4 | ||
| 5 | LM5UU | 4 | 4 | 5 | ||
| 6 | LM6UU | 4 | 7.6 | 6 | 0 -6 | 0 -9 |
| 8 | LM8SUU | 4 | 10.4 | 8 | ||
| 8 | LM8UU | 4 | 15 | 8 | ||
| 10 | LM10UU | 4 | 29.5 | 10 | ||
| 12 | LM12UU | 4 | 31.5 | 12 | ||
| 13 | LM13UU | 4 | 43 | 13 | ||
| 16 | LM16UU | 5 | 69 | 16 | ||
| 20 | LM20UU | 5 | 87 | 20 | 0 -7 | 0 -10 |
| 25 | LM25UU | 6 | 220 | 25 | ||
| 30 | LM30UU | 6 | 250 | 30 | ||
| 35 | LM35UU | 6 | 390 | 35 | 0 -8 | 0 -12 |
| 40 | LM40UU | 6 | 585 | 40 | ||
| 50 | LM50UU | 6 | 1,580 | 50 | ||
| 60 | LM60UU | 6 | 1,860 | 60 | 0 -9 | 0 -15 |
| 80 | LM80UU | 6 | 4,420 | 80 | ||
| 100 | LM100UU | 6 | 8,600 | 100 | 0 -10 | 0 -20 |
| 120 | LM120UU | 8 | 15,000 | 120 | ||
| 150 | LM150UU | 8 | 20,250 | 150 | 0 -13 | 0 -25 |
